Astell&Kern A&norma SR35
€899.00
A&norma SR35
Successor to a class leader
Included in the box
- 1x Astell&Kern A&norma SR35 player
- 1x USB-C to USB-C Cable
- 3x Screen protectors
- 1x Quick start guide
- 1x Warranty Card
General Specifications
Model
SR35
Body Colour
Charcoal Grey
Body Material
Aluminium
Display
3.6-inch HD 720 x 1280 px touch screen
Supported Audio Formats
WAV, FLAC, WMA, MP3, OGG, APE, AAC, ALAC, AIFF, DFF, DSF
Sample rate PCM
8kHz ~ 384kHz (8/16/24/32bits per Sample) DSD Native: DSD64(1bit 2.8MHz), Stereo / DSD128(1bit 5.6MHz), Stereo / DSD256(1bit 11.2MHz), Stereo
Output Level
[Normal] Unbalanced 2.1Vrms │ Balanced 4Vrms (Condition No Load) [High] Unbalanced 3.1Vrms │ Balanced 6Vrms (Condition No Load)
CPU
Quad-core
DAC
Cirus Logic CS43198 x4 (Quad-DAC)
Decoding
Support up to 32bit / 384kHz Bit to Bit playback
Input
USB Type-C input (for charging & PC & MAC)
Outputs
Unbalanced Out (3.5mm), Balanced Out (2.5mm, only 4-pole supported / 4.4m, only 5-pole supported)
Wi-Fi
802.11 a/b/g/n/ac (2.4&5GHz)
Bluetooth
V5.0 (A2DP, AVRCP, Qualcomm® aptX™ HD, LDAC)
Dimensions
2.51” (64mm)[W] x 4.26” (108.3mm)[H] x 0.63” (16.1mm)[D]
Weight
about 184g (6.49oz)
Firmware upgrade supported
(OTA)
Operating Temperature
0℃ ~ + 40℃ (32℉~ 104℉)
Audio performance
Frequency Response
- ±0.012dB (Condition : 20Hz~20kHz) Unbalanced │ ±0.011dB (Condition : 20Hz~20kHz) Balanced
- ±0.125dB (Condition : 20Hz~70kHz) Unbalanced │ ±0.126dB (Condition : 20Hz~70kHz) Balanced
S/N
- 127dB @ 1kHz, Unbalanced
- 130dB @ 1kHz, Balanced
Crosstalk
- -133dB @ 1kHz, Unbalanced
- -145dB @ 1kHz, Balanced
THD+N
- 0.0005% @ 1kHz, Unbalanced
- 0.0006% @ 1kHz, Balanced
MD SMPTE
- 0.0002% 800Hz 10kHz (4:1) Unbalanced
- 0.0002% 800Hz 10kHz (4:1) Balanced
Output Impedance
- Unbalanced Out 3.5mm (1.1ohm)
- Balanced Out 2.5mm, 4.4mm (2.7ohm)
Clock Source
Clock Jitter
25pS (Typ)
Reference Clock Jitter
70ps
Storage Capacity
Built-in Memory
64GB [NAND]
External Memory
microSD x1 (Max. 1TB)
Battery
Capacity
3,150mAh 3.7V Li-Polymer
Charge Time
about 2.5hours (5V 2A General Charging)
Playback Time
about 20hours (Standard : FLAC, 16bit, 44.1kHz, Normal Gain, Unbalanced, Vol.50, LCD Off, Dual DAC Mode)
Supported OS
Supported OS
Windows 10, 11(32/64bit) MAC OS X 10.7
